产品参数
| 产品型号Model | JQX-13F-L | |
| 外形尺寸Dimension(mm) | 27.3×21×35.2 | |
| 触点形式Contact Form | 2Z、2H、2D | |
| 触点材料Contact Material | 银锡合金AgSnO | |
| 触点容量阻性Resistance Performance Of Contactor Capacity | 10A/28VDC、10A/240VAC | |
| 线圈功率Coil Power | AC（VA） | 1.2 |
| DC（W） | 0.9 | |
| 线圈电压Coil Voltage | AC | 6～380V |
| DC | 6～220V | |
| 吸合电压Pick-up Voltage | DC：≤75%、AC：≤80%、 | |
| 释放电压Drop-out Voltage | DC：≥10%、AC：≥30%、 | |
| 最大电压Max Voltage | 110% | |
| 接触电阻Contact Resistance（mΩ） | 50mΩ | |
| 介质耐压Dielectric Strength | 开路触点间Between Open Contacts | 1200VAC |
| 触点组间Contacs Pieces | 1500VAC | |
| 线圈与触点间Between Coil&Contacts | 1500VAC | |
| 绝缘电阻Insulation Resistance（MΩ）at 500VDC | ≥100MΩ | |
| 工作寿命Service Life | 电气Electrical（次） | 100000 |
| 机械Mechanical（次） | 1000000 | |
| 环境温度Ambient Temperature（℃） | -25～+55℃ | |
| 引出端形式Terminal Type | 插拔式Insert Type | |
| 防护形式Protection Type | 封闭式Close Type | |
| 配用插座Suitable Socket | PTF08A/PTF08A-E | |
| 产品重量Product Weight（g） | 约40g | |
| 同类产品参照Same Reference | LY2NJ/HH62P-L | |
| 安装尺寸和线路图Installation dimensioms（mm）and connecting diagram |  | |
