产品参数
| 产品型号Model | HH54P/HH54P-L | |
| 外形尺寸Dimension(mm) | 27.3×21×35.2 | |
| 触点形式Contact Form | 4Z、4H、4D | |
| 触点材料Contact Material | 银合金Silver Alloy | |
| 触点容量阻性Resistance Performance Of Contactor Capacity | 3A/28VDC、3A/250VAC | |
| 线圈功率Coil Power | AC（VA） | 1.2 |
| DC（W） | 0.9 | |
| 线圈电压Coil Voltage | AC | 6VAC-380VAC |
| DC | 6VDC-220VDC | |
| 吸合电压Pick-up Voltage | ≤80% | |
| 释放电压Drop-out Voltage | ≥30% | |
| 最大电压Max Voltage | 110% | |
| 接触电阻Contact Resistance（mΩ） | 50mΩ | |
| 介质耐压Dielectric Strength | 开路触点间Between Open Contacts | 1000VAC |
| 触点组间Contacs Pieces | 1200VAC | |
| 线圈与触点间Between Coil&Contacts | 1500VAC | |
| 绝缘电阻Insulation Resistance（MΩ）at 500VDC | ≥100MΩ | |
| 工作寿命Service Life | 电气Electrical（次） | 100000 |
| 机械Mechanical（次） | 1000000 | |
| 环境温度Ambient Temperature（℃） | -25～+55℃ | |
| 引出端形式Terminal Type | 插拔式Insert Type | |
| 防护形式Protection Type | 封闭式Close Type | |
| 配用插座Suitable Socket | 18F-4C-C1/PYF14A/PYF14A-E | |
| 产品重量Product Weight（g） | 40g | |
| 同类产品参照Same Reference | MY4NJ/JZX-18F4Z | |
| 安装尺寸和线路图Installation dimensioms（mm）and connecting diagram |  | |
